    QF800 Electric Slurry Pump For Drilling Rig 800HP With Herringbone Gear

    Ask Lasest Price
    Brand Name : Hebei Pantu
    Model Number : QF800
    Certification : API 7K & ISO
    Price : 10000USD~50000USD
    Payment Terms : L/C,T/T
    Supply Ability : 20sets/month
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    QF800 Electric Slurry Pump For Drilling Rig 800HP With Herringbone Gear

    QF800 Slurry Pump For Drilling Rig 800HP


    Product Overview

    1. The RS-QF800 Slurry Pump is lighter than the RS-F800 mud pump by 1/3. its crankshaft is forged and fully balanced. The main wearing parts are the same as the RS-F800 mud pump.

    Key Features

    1. Durable Construction – Fabricated with high-strength alloy steel for longer service life under harsh drilling conditions.
    2. High Pumping Efficiency – Optimized fluid end design ensures steady displacement and minimal pulsation.
    3. Flexible Power Options – Compatible with both electric motor and diesel engine drives.
    4. Easy Maintenance – Modular design allows quick replacement of fluid end parts, reducing downtime.
    5. Enhanced Lubrication System – Combination of splash and forced lubrication for extended bearing life.
    6. API & ISO Compliance – Designed and manufactured according to API Spec 7K and ISO 9001 standards.

    Technical Specifications

    Liner Sizein170160150140130120110110
    Discharge PressureMpa13.8815.6717.8320.4723.7427.8633.1634.5
    psi
    2011
    2271
    2584
    2966
    3440
    4037
    4805
    5000
    Stroke per Minute
    (SPM)    		Power
    KW(HP)    		Displacement L/s(GPM)
    160
    616
    (825)
    39.96
    (633.38)
    35.38
    (560.78)
    31.11
    (493.10)
    27.08
    (429.23)
    23.36
    (370.26)
    19.90
    (315.42)
    16.72
    (265.02)
    13.82
    (219.05)
    *155
    *597
    (800)
    38.71
    (613.57)
    34.28
    (543.35)
    30.13
    (477.57)
    26.24
    (415.91)
    22.63
    (358.69)
    19.28
    (305.59)
    16.20
    (256.78)
    13.39
    (212.24)
    150
    577
    (774)
    37.45
    (593.59)
    33.18
    (525.91)
    29.16
    (462.20)
    25.39
    (402.44)
    21.90
    (347.12)
    18.66
    (295.77)
    15.67
    (248.37)
    12.96
    (205.42)
    140
    539
    (722)
    34.95
    (553.97)
    30.97
    (490.88)
    27.21
    (431.29)
    23.71
    (375.81)
    20.44
    (323.98)
    17.41
    (275.95)
    14.63
    (231.89)
    12.09
    (191.63)
    130
    500
    (670)
    32.46
    (514.50)
    28.75
    (455.70)
    25.27
    (400.54)
    22.01
    (348.87)
    18.98
    (300.84)
    16.17
    (256.30)
    13.58
    (215.25)
    11.23
    (178.00)
    120
    462
    (619)
    29.96
    (474.88)
    26.54
    (420.67)
    23.32
    (369.63)
    20.31
    (321.92)
    17.52
    (277.70)
    14.93
    (236.65)
    12.54
    (198.76)
    10.37
    (164.37)
    110
    423
    (567)
    27.46
    (435.25)
    24.33
    (385.64)
    21.38
    (338.88)
    18.62
    (295.13)
    16.06
    (254.56)
    13.68
    (216.83)
    11.49
    (182.12)
    9.503
    (150.63)
    1
    3.85
    (5.16)
    0.2497
    (3.9578)
    0.2212
    (3.5061)
    0.1944
    (3.0813)
    0.1693
    (2.6835)
    0.1460
    (2.3141)
    0.1244
    (1.9718)
    0.1045
    (1.6564)
    0.08639
    (1.36931)
    --Performance data are calculated by 90% mechanical efficiency and 100% volumetric efficiency.　　　　　　　　
    --The * present the recommendatory SPM and input power when the mud pump runs continuously.　　　　　　　　



    Slurry Pump Specification :

    Rated Input Power: 597 kW (800 HP)Stroke Per Minute: 155 SPM
    Stroke Length: 220 mm (8.66")

    Gear Ratio: 4.038:1
    Max.Working Pressure: 34.5 MPa (5000 psi)

    Valve: API#6
    Max.Liner Size : 170 mm(6 1/2")
    Suction Inlet Flange: 203 mm (8") flange
    Discharge Outlet Flange: 103 mm (4 1/16") flange, 34.5 MPa (5000 psi)Overall Dimension (L×WxH): 3583×1960×1534 mm3(11.76×6.43×5.03 ft3)Approx Weight: 11171 kg (24628 lb)

    Applications

    1. Onshore and offshore oil drilling rigs
    2. Geothermal drilling projects
    3. Coalbed methane drilling
    4. Large-diameter water well drilling

    Why Choose Our Mud Pump?

    1. Proven track record in Middle East, North America, Russia, and Africa oilfields.
    2. Global spare parts supply and after-sales service network.
